Key Features
Configurable, connected, and built to last.
Configurable Dual Pump Control
Venus gives you full Duty, Standby and Assist control forone or two pumps. Configure duty change logic around individual pump run time or numberof starts, so wear is shared across both pumps. Supports single phase 230V or three phase 400V operation, with up to four floats and/or a 4-20mA level sensor.
Smart Protections and IoT-Ready Logging
Built-in smart overcurrent, low voltage, brownout and max flow protection keep the pump and station safe. Up to 100 alarm logs and 400pump logs are date/time stamped and exportable for fault investigation or maintenancerecords. Add the optional N2P IoT daughter board for remote viewing and two-way controlfrom any compatible monitoring platform.
Live Operational Visibility
See what’s happening at the pump station in real time, voltageand current for each pump, pump starts and average run times, float status, recorded level,active alarms, and daily flow data from an optional flow meter input. When something goeswrong, you're not guessing.
Secure Wi-Fi Setup and On-Site Control
Venus generates its own protected Wi-Fi network.Connect from any phone or tablet to access the inbuilt webpages -- no software install, noapp, no cloud account, no fuss. Set duty change, low voltage, timed running, run windowand anti-freeze options, view live operation during commissioning, and pull pump and alarmlogs on site.
How it Works
Set ON and OFF times to activate flow output on your schedule. When your start/stop float is activated, the controller automatically powers the pump based on its timer settings.
To bypass the timer and power the pump, simply connect the timer override input to a high-level float or similar.
Technical Features
Fit for purpose and built to last.
Programmable ON and OFF settings from 1 second to 999:59 minutes
LCD screen shows active countdown – see how long until the pump comes on again
10A plug socket or terminal connections for power supply, timer start input and timer override input
